Powder Coated Gates and Fence Design

    Delivery Time: 15 Days
    Packaging: 1. rubber mat at the bottom of the pallet to avoid the pallet destroyed the panel. 2. 4 metal corners to keep the pallet more strong and wood plate on the panel pallet. 3. the metal plate under the plastic bandage to a pressure for fence panel.
    Brand: SHUNXING
    Place of Origin: Hebei, China (Mainland)
  • Mr. Mr. Jason He

Basic Info

Model No.: SX-WMF

Product Description

Specifications Gates and Fence Design

1.Excellent sureface treatment

2.Good anti-rust capacity from outside to inside

3.Competitive price

Powder Coated Gates and Fence Design   1. Gates and Fence Design Material:High quality low carbon iron Wire, galvanzied wire, black wire. 2. Gates and Fence Design Process:material---straighten and cutting---welded---galvanized/hot-dipped--making folds---parkerising---Powder coated--packing, please see the pictures as follows: 3. Gates and Fence Design Colors:Dark green, blue, white, red, yellow, black, gery,etc as your request. Dark Green is most popular for Exporting. 4. Gates and Fence Design Application:  Suitable for houses and properties, companies, gardens recreation areas, parks. All kinds of colors can be coated according to customers' special requirements. 5. Gates and Fence Design Common specification: Fence Panel:

The Common Specification of Fence Panel

Wire diameter

3mm—6mm,4mm/5mm is most popular

Mesh/Opening

50x100/50x150/50x200/60x100/60x200

75x150/75x200 as your request

Length of fence panel

2m,2.5m or as your request

Width of fence panel

1m,1.03m,1.2m,1.23m,1.5m,1.53m,1.7m,1.8m,2m,2.03m,2.4m,            as your request

Surface treatment

               Electric Galvanized then PVC Coated

               Electric Galvanized then Powder Coated

               Hot-dipped Galvanized then PVC Coated

               Hot-dipped Galvanized then Powder Coated

               Hot-dipped Galvanized or Electric Galvanized

 Gate Frame:

The type of the vertical-hinged door

Single leaf
Double leaf

Height of the gate(mm)

1.0m,1.2m,1.5m,1.8m,2.0m

Width of the gate(mm)

Single leaf: 1m,1.2m,1.5m
Double leaf: 2m,3m,4m,5m,6m,8m

Gate frame

Square tubes:
35X35mm, 40X40mm, 50X50mm, 60X60mm, 40x60mm

Surface treatment

Galvanized Steel pipe+Powder Coated

Color

RAL 6009 colors

  Gate Panel:

Wire diameter

3.8mm,4mm,4.8mm,5mm,6mm,

 mesh

50*100mm,50*150mm,50*200mm

height

1.5m,2.2m,2.4m,

post

40*60*1.5mm,60*60*2mm

Surface treatment

galvanzied then Powder coated,hot-dipped

 6. Gates and Fence Design Post: 7. Gates and Fence Design Packing:  we have 10 years export experience, we can provide the best packing to protect the goods. 1. rubber mat at the bottom of the pallet to avoid the pallet destroyed the panel.
2. 4 metal corners to keep the pallet more strong and wood plate on the panel pallet.
3. the metal plate under the plastic bandage to a pressure for fence panel.  Welcome to Inquiry!
